火星 月惑星研究会 関西支部 （最新）

ALPO-Japan Latest
Mars Image 2001/06/10

安達誠,冨田安明,Mars Orbiter Camera

M.Adachi,Y.Tomita,MOC

解説（安達）

　肉眼で南極冠というか南極フードがでこぼこした様子に観測された。ここしばらく、南極地方の雲の様子に注目されます。富田氏の画像からは、北極地方とマルラリティファー（Margaritifer Sinus;20°。-10°）付近に雲のかかっている様子が記録された。また、オピール（Ophir;65°、-5°）も相変わらず明るく観測されている。
Explanations M.Adachi
SPC was observed enevenly appearance. Margaritifer Sinus was covered by faint clouds. And, Ophir was bright seen today,too.
Makoto Adachi (Drawing: 310mm Newtonian)

2001/06/10 15h00m(UT)
CM=83.7 DE=+2.0
Ls=174.9 Dia.=20.1
Seeing;3/10 Transp.;1/5


透明度の悪い空での観測である。南極冠がでこぼこした形に見えたが、これは、フードの端を見ているのかもしれない。
Transparency was very bad condition today. The edge of the SPC formed unevenness. It seems that this edge may be SP hood's edge.
≪滋賀県　大津市　安達　誠≫

Yasuaki Tomita (255mmREF, Bitran 32L CCD Camera)
2001/06/10 16:26(UT)
seeing 7/10

大変この所天気が悪く雲の合間で
撮影している次第です、従って透明
度も大変悪くシャッタースピードも
普段の倍以上かかります。
撮影のあとしばらくして雲に覆われ
終了した。
Xp14mm f/50 Bitran 32L CCD Camera

≪群馬県佐波郡　冨田 安明≫


Mars Orbiter Camera
The wide angle cameras of the Mars Orbiter Camera (MOC) system onboard Mars Global Surveyor (MGS) are used every day to gather a global view of changes occurring in martian weather and surface frost patterns. Late in June 2001, as southern winter transitioned to spring, dust storm activity began to pick up as cold air from the south polar cap moved northward toward the warmer air at the martian equator. By early July, dust storms had popped up all over the planet, particularly throughout the southern hemisphere and in the Elysium/Amazonis regions of the northern hemisphere. Soon, the entire planet--except the south polar cap--was enshrouded in dust. Similar storms have occurred before. For example, the planet was obscured by dust when the Mariner 9, Mars 2, and Mars 3 spacecraft reached the planet in late 1971. The MGS MOC images showed the evolution of the 2001 great dust storm period. There was never a time when the entire planet was in the midst of a single storm. Several large storms would occur at the same time, and dust was kicked high into the atmosphere to cause much of the rest of the planet to be obscured. The dust storms largely subsided by late September 2001, but the atmosphere remained hazy into November of that year.The two pictures shown here come from the E05 (June 2001) and E06 (July 2001) subphases of the MGS MOC Extended Mission. The view from June shows the Tharsis volcanic region (left), Valles Marineris chasms (right) and the late winter south polar cap (bottom). The view from July shows the same regions, but most of the details are hidden by dust storms and haze.
South up South up Original image1380X1380 tif 4057kB



South up South up Original image2048X1536 jpg 1369kB
