木星 月惑星研究会 関西支部

Jupiter Image 2006/05/28(UT)

Randy Tatum,David Arditti,Christopher Go,Marc Delcroix,R.Mackintosh & M.Konishi
R.Tatum,D.Arditti,Christopher Go,M.Delcroix,M+K
Randy Tatum(250mm f/10 refl:ToUcam Pro)
Attached are two images from yesterday evening. Seeing was 8/10 and trans. 4/5. The 25.4 cm f/12 refl.,2x barlow,ToUcam Pro (no filter),Registax 3 and Photoshop Elements were used. Hope the favorable observing conditions continue !



[ Randy Tatum,Richmond,VA U.S.A]
David Arditti (250mm Dall-Kirkham Cassegrain:ATK camera)
A late clearance last night enabled me to get a few shots of Jupiter at the unusually low altitude of 18 degrees (good practice for the next 3 apparitions!)
I have tried a couple of new things here. Firstly,I have used an Atik x0.5 focal reducer screwed to the camera to decrease the EFL of the Dall-Kirkham-Dall telescope and increase image brightness (whoever heard of anyone using a focal reducer to image a planet before?) Secondly,I am trying a new IR filter,the Astronomik IR Pro 724 nm.
In the past I have tried IR filters at 685 nm,which seemed to give a result almost the same as R without IR block,and at 807 nm,which doesn't transmit enough detectable radiation with my set-up for Jupiter.
The 724 nm filter seems to be a successful compromise,particularly at revealing the bright spot in the NTrZ (or is it the NTB?),which is not very apparent in the visible light image.

[David Arditti: Edgware Middlesex HA8 5LW: United Kingdom]
Christopher Go (Celestron C11,DMK21BF04 monochrome camera)
This is probably one of my best image of Jupiter! I have finally resolved a hint of the spiral vortex inside Oval BA!! This was very clear on the HST image.
Both the GRS and Oval BA are moving very closer now! They will have a conjunction in mid-July!

[Christopher Go : Cebu Philippines]
Marc Delcroix (254mm SC)


[Marc Delcroix Tournefeuille,France]
Mackintosh.Roberto & Konishi.Monicat(300mm SCT)

[ブエノスアイレス：アルゼンチン]
[Mackintosh.Roberto & Konishi.Monicat: Buenos Aires-Argentina]
